2 Introduction

ThisseriesofdisplayunitissuitableforHTLimpulsesignalsandpanelmounting.Itisvery

versatileinuse,duetotheintuitivehandlingandtheextensiverangeoffunctionsand

options.

2.1 Operationmode

Allfunctionsarecanbeconfiguredintheparametermenu.

Thedevicecanbesettooneofthefollowingoperationmodes:

•SPEED(onlyinputAisused)

‐ Tachometers/speedindicator

‐ Measurementoffrequency/RMPindicator

‐ Monitoringfunctionsforspeedandstandstill

•PROCESSTIME(onlyinputAisused)

‐ Processingtimeindicator(reciprocalspeed)

‐ Bakingtimeindicator

‐ Flowtimeindicator

•TIMER(onlyInputAorInputBareused,dependingontheparametersetting)

‐ Operationasstopwatch(start‐/stopfunctioncanbefreelyparameterized)

‐ Counterforoperationhours

‐ Periodmeasurement

‐ Totaltimemeasurement

•COUNTER(inputAandinputBareused)

‐ Pulsecounter/sumordifferentialcounter

‐ Up‐ordowncounter

‐ Positionindicator

‐ Quadraturecounter

‐ Batchcounter/totalcounter

•VELOCITY(inputAoperatesasastartinputandinputBoperatesasastopinput)

‐ Runtimemeasurementasspeedindicator.


