Only the front side is classified as accessible
for the operator.
Application area: Pollution level 2
over-voltage Category II
Insulation: Front: double insulation,
Rear side: basic insulation,
Signal inputs and und sensor power supply: SELV
10.12 Mechanical Data
Housing: Panel-mount housing
to DIN 43 700, RAL 7021
Dimensions: 48 x 48 x 91 mm
Panel cut-out: 45
+0,6
x 45
+0,6
mm
Installation depth: ca. 107 mm incl. terminals
Weight: ca. 125 g
Protection: IP65 (front, device only)
Housing material: Polycarbonate UL94 V-2
Vibration resistance: 10 - 55 Hz / 1 mm / XYZ
(EN 60068-2-6): 30 min in each direction
Shock resistance:
EN 60068-2-27 100G / 2 ms / XYZ
3 times in each direction
EN 60068-2-29 10G / 6 ms / XYZ
2000 times in each direction
10.13 Connections
Supply voltage and outputs:
Plug-in screw terminal, 7-pin, RM5.08
Core cross section, max. 2.5 mm²
Signal and control inputs:
Plug-in screw terminal, 8-pin, RM 3.81
Core cross-section, max. 1.5 mm²
11 Scope of Delivery
Delivery includes:
Preset counter
Mounting clip
Instruction manual
12 Ordering codes
6.924.X1XX.XX0
Input trigger levels
0 = Standard (HTL)
A = 4-30 VDC*
Supply voltage
0 = 100… 240 V AC ± 10%
2 = 24 VAC +/- 10%
3 = 10 .. 30 VDC
LCD version
0 = no backlighting
1 = green backlighting*
2 = LED Look*
3 = Multicolour
Outputs
0 = Relay
1 = Optocoupler*
Front
0 = Kübler version
A = Neutral version*
* 24 VAC power supply on request
13 Frequencies (typical)
13.1 Pulse counter
HTL level
AC supply typ. Low 2,5 V
typ. High 22 V
DC supply 12V typ. Low 2 V
typ. High 10 V
DC supply 24V typ. Low 2,5 V
typ. High 22 V
Add
Sub
Trail
AddAr
SubAr
AddBat
SubBat
TrailAr
AddTot
SubTot
Cnt.Dir
55 kHz 2,8 kHz 2,7 kHz
Up.Dn
Up.Up
29 kHz 2,8 kHz 2,7 kHz
Quad
Quad 2
28 kHz 1,4 kHz 1,3 kHz
Quad 4
18 kHz 1,2 kHz 0,9 kHz
A/B
(A-B)/A
29 kHz
