Kubler Codix 924 - Frequency Meter

4-30 V level
typ. Low 1,0 V
typ. High 4,0 V
Add
Sub
Trail
AddAr
SubAr
AddBat
SubBat
TrailAr
AddTot
SubTot
Cnt.Dir
9 kHz 2,7 kHz 2,4 kHz
Up.Dn
Up.Up
9 kHz 2,7 kHz 2,4 kHz
Quad
Quad 2
9 kHz 1,2 kHz 1,2 kHz
Quad 4
9 kHz 1,2 kHz 0,9 kHz
A/B
(A-B)/A
9 kHz
13.2 Frequency meter
HTL level
AC supply typ. Low 2,5 V
typ. High 22 V
DC supply 12V typ. Low 2 V
typ. High 10 V
DC supply 24V typ. Low 2,5 V
typ. High 22 V
4-30 V level
typ. Low 1,0 V
typ. High 4,0 V
HTL 5V
A
65 kHz 9 kHz
A – B
A + B
A / B
(A-B)/A
65 kHz 9 kHz
Quad
30 kHz 9 kHz
NOTE: Switching levels of the input
Switching levels with AC supply:
HTL level Low: 0 .. 4 VDC
High: 12 .. 30 VDC
4-30 V level Low: 0 .. 2VDC
High: 3,5 .. 30 VDC
Switching levels with DC supply:
HTL level Low: 0 .. 0,2 x UB
High: 0,6 x UB .. 30 VDC
4-30 V level Low: 0 .. 2 VDC
High: 3,5 .. 30 VDC
e
n
g
l
i
s
h
