Kubota B2301-1 Workshop Manual

BRAKES
B2301, B2601, WSM
4-S2
2. SERVICING SPECIFICATIONS
9Y1211156BRS0002US0
Item Factory Specification Allowable Limit
Brake Pedal Free Travel
Difference of
Stroke
(RH and LH)
30 to 40 mm
1.18 to 1.57 in.
–
–
0 to 5 mm
0 to 0.1 in.
Cam Plate and Bearing Holder Flatness – 0.30 mm
0.012 in.
Cam Plate and Ball Height 22.89 to 22.99 mm
0.9012 to 0.9051 in.
22.40 mm
0.8819 in.
Brake Disc Thickness 3.30 to 3.50 mm
0.130 to 0.137 in.
3.0 mm
0.12 in.
Friction Plate Thickness 1.92 to 2.08 mm
0.0756 to 0.0818 in.
1.52 mm
0.0598 in.
KiSC issued 11, 2014 A
