BRAKES
B2650HSDC, B3350HSDC, WSM
4-S3
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: See page G-11.)
9Y1210822BRS0003US0
Item N·m kgf·m lbf·ft
Steering wheel mounting nut 30 to 49 3.0 to 5.0 22 to 36
Rear wheel mounting nut 167 to 191 17 to 19.5 123 to 141
Rear wheel mounting bolt 196 to 225 20 to 23 145 to 166
Front loader valve pipe joint bolt 48 to 55 4.9 to 5.7 36 to 41
3-point hitch delivery pipe 1 joint bolt 48 to 55 4.9 to 5.7 36 to 41
3-point hitch delivery pipe joint bolt 50 to 59 5.1 to 6.1 37 to 44
3-point hitch delivery pipe 2 joint bolt (Front loader
valve side)
48 to 55 4.9 to 5.7 36 to 41
3-point hitch delivery pipe 2 joint bolt (Hydraulic cylinder
case side)
50 to 59 5.1 to 6.1 37 to 44
Rear axle case mounting screw 40 to 44 4.0 to 4.5 29 to 32
Sub frame mounting screw (M10) for aluminum 40 to 44 4.0 to 4.5 29 to 32
Sub frame mounting screw 48 to 55 4.9 to 5.7 36 to 41
Sub frame mounting bolt (M12) and nut 78 to 90 7.9 to 9.2 58 to 66
