HYDRAULIC SYSTEM
B2650HSDC, B3350HSDC, WSM
7-S3
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: See page G-11.)
9Y1210822HYS0003US0
Item N·m kgf·m lbf·ft
Power steering delivery hose nut 24 to 28 2.5 to 2.8 18 to 20
Rear wheel mounting nut 167 to 191 17 to 19.5 123 to 141
Rear wheel mounting bolt 196 to 225 20 to 23 145 to 166
Universal joint mounting bolt 24 to 28 2.5 to 2.8 18 to 20
Cabin mounting bolt and nut 124 to 150 12.7 to 15.2 91.5 to 110
Front loader valve pipe joint bolt 48 to 70 4.9 to 7.1 36 to 51
3-point hitch delivery pipe 1 joint bolt 48 to 70 4.9 to 7.1 36 to 51
3-point hitch delivery pipe 2 joint bolt (front loader
control valve side)
48 to 70 4.9 to 7.1 36 to 51
3-point hitch delivery pipe 2 joint bolt (hydraulic cylinder
case side)
50 to 60 5.1 to 6.1 37 to 44
Hydraulic pump cover mounting screw 35 to 39 3.5 to 4.0 26 to 28
