REGULAR CHECKS AND MAINTENANCE WORK80
EVERY 500 SERVICE HOURS
Do all 50, 100 and 250 hour servicing at the same time.
BChanging Engine Oil (Change the engine
oil every 500 hours, or every 1 year in the
case that service hour is less than 500
hours)
To avoid personal injury or death:
A First stop the engine then remove the key and
wait long enough for the oil to cool down.
1. Remove the drain plug on the underside of the engine
and drain all oil.
2. Re-tighten the drain plug.
3. Fill up with new oil through the filling port to the
specified level.
(1) Dozer cylinder boss
(2) Dozer linkage boss
(1) Dozer cylinder boss
(2) Dozer linkage boss
(1) Drain plug
(1) Oil filling port
(2) Engine oil dipstick
(A) Required oil level range
