10-S6
L3540, L4240, L5040, L5240, L5740, WSM
CABIN
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : Refer to “5. TIGHTENING TORQUES” at “G. GENERAL” section.)
W1046254
Item N·m kgf·m lbf·ft
Outer roof mounting screw 3.5 to 4.0 0.36 to 0.40 2.6 to 2.9
Cabin mounting bolt and nut 124 to 147 12.6 to 15.0 91.2 to 108
High pressure pipe and low pressure pipe mounting
screw
7.9 to 11 0.80 to 1.2 5.8 to 8.6
Compressor mounting screws 25 to 29 2.5 to 3.0 18 to 21
Clutch mounting screw 12.3 to 14.1 1.25 to 1.44 9.05 to 10.4
A/C unit mounting screw (M6) 4.0 to 6.8 0.40 to 0.70 2.9 to 5.0
A/C unit mounting screw (M8) 9.81 to 11.6 1.00 to 1.19 7.24 to 8.60
Low pressure pipe (Cooler pipe (suction)) retaining nut 30 to 34 3.0 to 3.5 22 to 25
High pressure pipe (Cooler pipe (liquid)) retaining nut 12 to 14 1.2 to 1.5 8.7 to 10
High pressure pipe 1 mounting screw (Compressor
side)
7.95 to 11.7 0.80 to 1.20 5.86 to 8.67
High pressure side 1 retaining nut (Condenser side) 20 to 24 2.0 to 2.5 15 to 18
High pressure pipe 2 retaining nut (Receiver side) 12 to 14 1.2 to 1.5 8.7 to 10
Low pressure pipe mounting screw (Compressor side) 7.95 to 11.7 0.80 to 1.20 5.86 to 8.67
High pressure pipe 2 retaining nut 12 to 14 1.2 to 1.5 8.7 to 10
Low pressure pipe retaining nut 30 to 34 3.0 to 3.5 22 to 25
Wiper motor mounting nut (4) 6.4 to 9.3 0.65 to 0.95 4.7 to 6.8
