Kubota WSM B2350 User Manual

CABIN
B2050, B2350, B2650, B3150, WSM
10-S5
2. SERVICING SPECIFICATIONS
A/C
ELECTRICAL PARTS
9Y1210982CAS0002US0
Item Factory Specification Allowable Limit
Refrigerating Cycle
(Refrigerating Cycle is Normal Operating)
Pressure
(LO Pressure Side)
0.15 to 0.20 MPa
1.5 to 2.0 kgf/cm
2
21 to 28 psi
–
Pressure
(HI Pressure Side)
1.27 to 1.66 MPa
13 to 17 kgf/cm
2
185 to 242 psi
–
Air-gap of A/C Compressor Magnet Clutch Air gap 0.30 to 0.65 mm
0.012 to 0.025 in.
–
Air Conditioner Drive Belt Tension 10 to 12 mm
(0.39 to 0.47 in.)
deflection at 98 N
(10 kgf, 22 lbf) of force
–
Pressure Switch (Dual Type)
(When pressure switch is turned OFF)
Setting Pressure
(LO Pressure Side)
Less than approx.
0.196 MPa
2.0 kgf/cm
2
28.4 psi
–
Setting Pressure
(HI Pressure Side)
More than approx.
3.14 MPa
32 kgf/cm
2
455 psi
–
Item Factory Specification Allowable Limit
Stator Coil Resistance
1P Connector
3.0 to 4.0  –
A/C Blower Switch Connector Voltage
a Te r m ina l –
b Te r m ina l
Approx. battery voltage –
A/C Blower Resister Resistance
R1 Terminal –
E Terminal
Approx. 0.56  –
Resistance
R2 Terminal –
E Terminal
Approx. 1.56  –
Front Wiper Switch Connector Voltage
W Terminal –
Chassis
Approx. battery voltage –
