Putting into service
Disc mower
GMD240-280-310
41
KN204AGB H
 Uncoupling the machine
- Place the cutterbar in horizontal position.
- Release parking lock (1).
- Engage parking latch behind the bevel gearbox
mounting plate (2).
Tractor not fitted with a hydraulic position control
function:
See section: Optional equipment / Chain stroke
limiter.
When optional equipment is used, follow
specific procedures mentioned in the related
section:
• Optional equipment / Chain stroke
limiter.
- Make sure no foreign material is located
on the bevel gearbox.
- Check that there are no foreign bodies in
front of the leg stop (1).
1
1
2
1
