Optional equipment
Rotary cultivators
EL22
33
$Optional equipment
1. Transmission with friction slip clutch
Part no. 4700053.
Check the condition of the friction slip clutch:
- Loosen nuts to release friction discs (a).
- Let the friction discs slip for a few seconds (b).
- Tighten nuts until distance (L) is 28.5 mm (1.13’’).
The friction slip clutch is ready to function.
Do not fully tighten springs to prevent
damage on drive elements.
Loosen at least by 1/2 turn.
