KUHN FC313 RF - Machine Specifications; Description and Glossary

Machine specifications
Mower conditioner
FC313 RF
19
$MACHINE SPECIFICATIONS
1. Description and glossary
0
1 : Headstock 2 : Mowing unit
3 : Parking stand 4 : Lateral parking stand
5 : Hydro-pneumatic accumulators 6 : Swath shield
7 : Transport lock lever 8 : Cutterbar
9 : Central gearbox 10 : Side gearbox
11 : Lift cylinder 12 : Pressure gauge
13 : Conditioning roller 14 : Transport lock
15 : Side guard
