Instructions for transport
Mower conditioner
FC313 RF
35
$INSTRUCTIONS FOR TRANSPORT
1. Setting the machine into transport
position
From the working position:
- Release and fold side guards upwards using 18mm
box spanner supplied with the machine.
- Lift transport lock lever in transport position.
- Lift mowing unit using machine lift cylinders to engage
transport locks.
- The machine automatically locks in transport position.
The machine is in transport position.
Before placing the machine into transport
position:
Wait until the rotating parts have come to a
complete stop.
Check that transport locks are engaged.
If the machine transport locks do not engage
automatically:
- The spacer is distorted (1).
- Replace spacer.
Never engage the tractor PTO drive when the
machine is in transport position.
1
