Mower conditioner
56
FC313 RF
Maintenance and storage
Every 250 hours
Secondary PTO shaft
The grease zerks of the secondary PTO shaft U-joints
and guiding bushes are accessible by unlocking the 2
clips of the 2 guard cones.
The telescopic tubes are lubricated through a grease
zerk:
- Slide the black collar.
- If necessary, rotate a disc to access the grease zerk.
- Slide the black collar back in place when lubrication
has been completed.
Place the machine in working position.
Stop the tractor engine and remove ignition
key.
Remove secondary pto shaft for easier access to
grease zerks.
