KUHN RPB User Manual

General description
Control box
RPB
15

Entry and modification of a value
- Press keys (1) and (2) to select the parameter to
modify:
• Move the cursor upwards (1).
• Move the cursor downwards (2).
- Press key (3) to modify parameter.
Numerical value:
- Press keys (1) or (2) to modify the value:
• Increment a value (1).
• Decrement a value (2).
• Value reset (3).
- Validate (4).
or
- Cancel the modification (5).
Alphabetical value:
- Press keys (1) or (2) to select the value to modify:
• Move the cursor to the right (1).
• Move the cursor to the left (2).
- Press keys (3) or (4) to modify the value:
• Increment a value (3).
• Decrement a value (4).
• Value reset (5).
- Validate (6).
or
- Cancel the modification (7).
3
1
2
3
1
2
5
4
5
3
4
7
6
2
1
