KUHN RPB User Manual

Trouble shooting guide
Control box
RPB
65
3. Description of fuses
The cards are made up of 4 tie-point blocks:
- (1) Signalling.
- (2) Outputs.
- (3) Sensors.
-(4) BUS CAN.
The terminal blocks have 3 levels:
(1) High.
(2) Middle.
(3) Low.
Prior to any maintenance or repair on the
junction box, disconnect the machine and
tractor power supply.
Never replace damaged fuse by a fuse of
higher value.
Keep fuses safe from rain and humidity.
4
3
2
1
3
2
1
