Putting into service
Control box
RPB
19
$
Putting into service
1.
Switches on th
e control box
-
Press key (1) to switch the control box on.
-
Press key (1) for 2 seconds to sw
itch the control box
off.
2.
Standby mode
The control box RPB switches to the sta
ndby mode
when not used for a few minutes.
-
Press on a key to exit the standby mode.
