Control box
14
RPB
General description
4.
Access and me
nu navigation
î
Navigation keys
To navigate in the m
enus,use the following keys:
-
Menu line
change key
(1
).
-
Selection validation key
(2).
-
Key to return to the previous me
nu
(3).
Menu display
(1).
The RPB control box fe
atures circular menus.
1
2
1
3
1
15
17
