Control box
70
RPB
Trouble shooting guide
4.
Factory counters
As from the "Terminal" menu:
-
Press key (1) to access "Counters" menu.
-
Press on th
e button (2).
The control box displays
the following information:
-
Total area.
-
T
otal volume.
Main menu
Configuration
Terminal
Operating data
These counte
rs cannot be delete
d.
2
1
71
73
