Instructions for work
SpeedRake
SR108 SR110 SR112
25
$Instructions for work
1. Place the machine in working
position
From the transport position:
- Stop the tractor engine and remove ignition key.
- Remove the link bar (1) from the transport locked
position.
- Install the link bar (1), attaching it to the "R+L" position
on the primary pivot.
- Install the retaining pin to secure the link bar (1).
- Activate the tractor hydraulics and lower the rake
arms to the working position.
- Place the tractor hydraulics in "float" mode just before
the rake wheels contact the ground.
The machine is in working position.
Before placing the machine in working
position:
- Check that nobody is within the machine
pivoting area.
- If there is someone, make sure the person
moves away.
The tractor hydraulics must be set to "float"
mode during operation.
