15-10
Advanced KDFX
Effects Buses
There is no external level control over the output of the FXBus itselfÑit just shows up, in pre-
effect and post-effect versions, on the OUTPUT page.
Figure 15-4 FXBus Signal Routing
The Aux Bus
The Auxiliary effects bus is accessed by pressing the AUXFX soft button on any page in the
Studio Editor. It contains an FX preset, which is separate from those in the insert FXBusesÑ
although it can be the same FX preset that is in use on one or more of the insert FXBuses. There
is no Allocation parameter, because the Aux bus has a Þxed allocation of 3 PAUs. Only a very
few highly complex FX presets require more than 3 PAUs, so as you scroll through the
FX presets here you wonÕt see many names in parentheses.
Aux Bus Outputs
There are two outputs from the Aux bus: itself, and a feed (post-effect) to the Mix bus. The feed
to the Mix bus, where it is combined with other Mix bus feeds from the four FXBuses, has level
and balance controls. The Aux busÕs own output has no post-effect controls, and goes right to
the OUTPUT page.
Pre FXBus
FXBus
From Input editor
to Mix
bus
to Aux
FX bus
To Output editor
