15-20
Advanced KDFX
Saving Studios and Other objects
2. Set the Input parameter to Digital, then set the Out parameter, if available, to A/D. This
causes the digital outputs to mirror the signal coming from the K2600Õs Mix outputs. (Set
the Out parameter to Dir to mirror the Output A signal at the digital outs.)
Note: If you donÕt have the Digital I/O option, you wonÕt see the Out parameter, which means that
the digital output mirrors the K2600Õs Mix outputs.
When the Input parameter is set to Analog and the Src parameter is set to Ext, the signal that
appears at the digital output is the signal coming into the K2600Õs external analog inputs, and the
K2600 is acting as a very fancy, very high-quality A/D converter.
Saving Studios and Other objects
Saving
Saving a studio or an FX preset is handled the same as any other K2600 objectÑsee Saving and
Naming on page 5-3 if you need help with this.
To save an object, from any of the editing pages within the object, press <more or more>, until
you see the Þle-management pages:
<more||Name|||Save|||Delete|Dump|||more>
Name lets you rename the object, using the standard K2600 naming window. Save lets you save
the object to its present slot or to a different one, and also gives you the option of renaming it
before saving it, or accessing the Object utilitiesÑsee Chapter 13.
Delete deletes the object from RAM. If it is in a slot where there is a ROM studio or FX preset,
then the slot will revert to the ROM studio or FX preset.
Dump performs a MIDI System Exclusive dump of the object over the MIDI Out cable for
external storage.
The Save option is automatically invoked if you have done any editing within an object and you
press Exit.
Do I Always Have to Make a New Studio?
While it may sound as if every time you make a change in a studio parameter, you have to create
a new studio to save it, this is not necessarily true. Studios do take up room in program RAM,
and although the number of studios that can be maintained inside the K2600 is large, it is not
unlimited. Besides, it can be very cumbersome keeping track of a large number of studios which
have only small differences between them.
Value of Out Parameter Value of Src Parameter Signal at Digital Output
Dir N / A KDFX Output A
A / D Int K2600 Mix Output
A / D Ext K2600 Analog Input
Table 15-1 Digital Output Switch Settings
