Advanced KDFX
Output Section
15-19
Separate Analog and KDS Outputs
The K2600Õs separate analog outputs (four pairs, AÐD) are wired in parallel and are ÒliveÓ at all
times. So are the eight digital outputs (also four stereo pairs) available with the digital I/O
(KDS) upgrade option. The parameters on the OUTPUT page affect both the separate analog
and KDS outputs.
Analog Mix Output
The K2600Õs analog Mix output combines the four output pairs into a single stereo analog pair.
Each of the analog outputs, AÐD, carries the signal from the KDFX bus speciÞed for each output
pair on the OUTPUT page of the Studio Editor. The signal at the Mix output always carries the
summed signal of outputs AÐD; connecting cables to Outputs AÐD does not remove the
corresponding portion of the signal from the Mix outputs.
Figure 15-9 K2600 Analog, Digital, and KDS Outputs
Digital Output
For digital output, youÕll need either the sampling option or the digital I/O (KDS) option. In
either case, the digital output of the K2600 (a single stereo pair) is wired in parallel with output
pair A. It gets whatever signal is routed to Output A on the OUTPUT page of the Studio Editor.
With the digital I/O option, you can use the XLR or optical outputs, or the separate KDS outputs
(although this requires the Kurzweil DMTi digital interface for full functionality). With the
sampling option, you can use the XLR or optical outputs.
The sampling option also enables you to sample the K2600Õs own output.
1. On the Sample-mode page, set the Input parameter to Analog, and the Src parameter to
Int. This routes the signal at the K2600Õs Mix outputs to the analog sampling input,
ignoring the external sampling inputs on the rear panel.
KDFX Bus Output
Mix
A DCB K2600 Physical Outputs
(Analog) (Analog,
Digital, or
KDS)
(Analog
or KDS)
(Analog
or KDS)
(Analog
or KDS)
