Chapter 2 Assembly
DC Power Adapter
(DC15V, 2.5A) with Power Cord
If you are missing any of the above, Please contact your Kurzweil dealer
User Manual Smart I/O Cable
➏ ➐ ➑ ➒ ➓
➏
Bolts for side panels and keyboard
Bolts for side panels
and keyboard
4
➐
Bolts for side panels and pedal box
Bolts for side panels
and pedal box
4
➑
Bolts for rear panels and side panel
Bolts for rear panels
and side panel
2
➒
Bolts for rear panels and pedal box
Bolts for rear panels
and pedal box
4
➓
Cable clamps 2
➊
Keyboard (main unit)
Keyboard(main unit)
1
➋
Side panel of stand (left)
Side panel of
stand(left)
1
➌
Side panel of stand (right)
Side panel of
stand(right)
1
➍
Pedal box
Pedal box
Pedal support bolt
1
➎
Rear panel
Rear panel
1
➊
➌
➋
➑
➐
➍
➏
➎
➒
Carton Contents
Accessories
To Next Page
