17
© Küschall AG, Schweiz | 2012-07
Service manual
Footrests
Fitting and adjusting high-mounted footrest
Diculty:
Tools:
à 4, 5 8, 10
Fit the frame bar for the high-mounted footrest to the front frame on
both sides using the screw connections .
Fix the clamp set to both sides of the frame using the screw
connection . Only tighten lightly.
Slide the high-mounted footplate into the clamp set and to the
desired height.
Tighten the screw connections on both sides.
Angle-adjustable footplate, adjusting the angle
Diculty:
Tools:
à 4 10
To adjust the angle, release the four screw connections until the
footplate can be moved.
Check and/or adjust the distance between the left and the right sides
by pushing in or pulling out the tubes below the footplate in such a way
that the bearings blocks are perpendicular to the ground.
Tilt the footplate into the desired position and tighten the screw
connections .
j
The angle of the footplate must be set so that the user’s feet cannot
slide o the plate.
Fit fold-up footrest
Diculty:
Tools:
à 4, 5 8, 10
Fix the reinforcing bar to the frame and position it so that the
bearings blocks are perpendicular to the ground. Then, rmly tighten
the screw connection .
On both sides, slide the telescopic tubes into the frame. On both
sides, x the telescopic tubes at the desired height using the screw
connection .
Carry out the same setting on both sides.
Insert the sleeve into the mounting part of the right telescopic
tube. Fix it using the screw .
Place the left tube of the footplate into the mounting part on both
sides of the left telescopic tube, each with a washer. Fix it using the
screw .
Insert the right tube of the footplate into the mounting part of the right
telescopic tube. Adjust the distance between the left and the right sides
by pushing in or pulling out the tubes below the footplate in such a way
that the bearings blocks are perpendicular to the ground.
Tilt the footplate into the desired position and tighten the footplate
screws, ‹Angle-adjustable footplate, adjusting the angle›.
i
The footrest can also be tted the other way around (right footrest
tube xed, left tube moving).
1
4
5
2
3
à 7Nm
à 7 Nm
1
1
à 13 Nm
2
3
4
5
7
9
8
1
6
à 7 Nm
à 7 Nm
à 7 Nm
à 7 Nm
