TracVision TV5 User’s Guide
13
Getting Started
Turning On the System
To turn on your TracVision system, follow these steps:
1. Make sure the antenna has a clear, unobstructed view of the
sky.
2. At the rear panel of the TV-Hub, set the power switch to the On
(|) position. The TV-Hub supplies power to the antenna.
Figure 2-3 Power Switch (TV-Hub A shown)
3. Wait a few minutes for system startup.
4. Once the antenna finds the selected satellite, all three status
lights on the TV-Hub should be lit green. If any lights are not lit
green, refer to “TV-Hub Status Indicators” on page 87.
Figure 2-4 Status Lights
Important!
During startup, the TV-Hub checks the software versions installed in
the antenna and updates them if necessary to match the versions it
has stored for that model. All three status lights will alternate orange
while this update is in progress. Do not turn off the system during
this time. Updates might take up to 40 minutes.
