TracVision TV5 User’s Guide
19
Network Settings
TV-Hub Ethernet Settings
By default, the Ethernet port of the TV-Hub is configured for Dynamic
mode. This means that, when the TV-Hub is connected to an onboard
network, the network’s router assigns it an IP address. Most routers
are normally configured as a DHCP (dynamic host configuration
protocol) server.
NOTE: On startup, if the TV-Hub does not detect a DHCP server within a
few seconds, it automatically assigns itself a static IP address: 169.254.253.1.
If you want to assign a specific IP address to the TV-Hub, you can
configure the TV-Hub for Static mode at the Settings page of the web
interface (go to Settings > Network Settings). When you select Static
mode, you will need to enter the desired IP address, along with its
associated subnet, gateway address, and broadcast address. These
settings require networking expertise.
Figure 3-2 Ethernet Settings
Important!
If your system is set up for automatic satellite switching for DIRECTV,
make sure your DIRECTV receiver(s) have IP addresses in the same
subnet as the TV-Hub. If your system includes IP AutoSwitches for
automatic satellite switching, make sure they are all on the same local
LAN segment as the TV-Hub.
