KYMCO AGILITY300 User Manual

Read this Manual carefully
This Owner's Manual contains important information on safety, operation and maintenance
of KYMCO AGILITY300. Anyone who is going to ride should carefully read and understand
the contents of this manual before riding. For personal safety, understand and follow all of
the warnings contained in this Owner's Manual and the labels attached on vehicle. This
Owner's Manual should be considered a permanent part of the vehicle, keep it with the
scooter. ON-ROAD USE ONLY for this scooter
.
Par ticular ly important infor mation is provided in this manual by the
following symbols and signal words:
The SAFETY ALERT symbol means ATTENTION! BE ALERT!
YOUR SAFETY CAN BE AFFECTED.
WARNING
CAUTION
NOTE:
Failure to follow these instructions can result in severe injury or death.
These instructions point out the special precautions must be followed
to avoid damage.
The NOTE indicates the additional important information.

KYMCO AGILITY300 Specifications

Capacities

engine oil capacity (exchange)	0.9 L
transmission oil capacity (exchange)	0.18 L
fuel tank capacity	13 L
maximum weight capacity	341 kg

Engine Specifications

engine type	Four-stroke, air-cooled OHC
engine displacement	276 cc
bore and stroke	72.7 X 66.4 mm
compression ratio	10.6:1
max horsepower	16.8 KW/7500 rpm
max torque	23.5 Nm/6500 rpm
spark plug	DPR6EA-9
idle speed	1700±100 RPM
cooling system	Cooling water
starting system	Electric starter motor

Chassis

tire size, front	110/70–16
tire size, rear	140/70–14
brake, front	DISK(ABS)
brake, rear	DISK(ABS)

Electrical

ignition type	ECU
battery	12v 10Ah
headlight	12v/8w/6w
tail light	12v 4w
brake light	12v 6w
turn signal light	12v 10w 2
license plate light	12V 5w
position light	12v 5w(F)12v 1w(B)
fuses	30A 1, 25A 1, 15A 2, 10A*2

Weight and Dimensions

overall length	2200 mm
overall width	765 mm
overall height	1560 mm
wheel base	1550 mm
seat height	800 mm
curb weight	191 kg
