KYMCO AGILITY300 - Specifications

64
SPECIFICATIONS
Dimensions
Overall length ..............................2200mm
Overall width................................. 765 mm
Overall height .............................. 1560 mm
Wheel base................................. 1550 mm
Seat height ....................................800 mm
Curb weight......................................191 kg
Capacities
Engine oil (exchange)..........................0.9 L
Transmission oil (exchange).............. 0.18 L
Fuel tank .......................................... 13 L
Maximum weight capacity ................ 341kg
Engine
Type ............ Four-stroke, air-cooled OHC
Displacement...................................276cc
Bore and stroke...................72.7 X 66.4 mm
Compression ratio ............................10.6:1
Spark plug ................................DPR6EA-9
Idle speed ..........................1700±100RPM
Cooling system ................... Cooling water
Starting system ......... Electric starter motor
..
..
Max Horsepower...... ........16.8KW/7500rpm
Max Torque............. .........23.5Nm/6500rpm
Chassis
Tire size, front............................. 110/70–16
Tire size, rear............................. 140/70–14
Brake (front) .............................DISK(ABS)
Brake (rear) ...............................
Electrical
Ignition type ........................................ ECU
Battery ...................................... 12v 10Ah
Headlight ........................ 12v/8w
Tail light ......................................... 12v4w
Brake light .................................... 12v 6w
Turn signal light ...........................12v 10w*2
License plate light.............................12V 5w
Position light..................12v 5w
Fuses ................30A*1, ,15A*2,
DISK(ABS)
..
........... /6w
...
...
(F)12v 1w(B)
25A*1 10A*2
