MAINTENANCE
3
4
5
6
1. Stand the scooter by the center stand.
2. Remove the gear oil drain bolt .
3. Remove the gear oil filler bolt ,and
then slowly rotate the rear wheel to drain
the gear oil off.
4. Fill with the recommended oil to reach
the capacity listed below.
5. Install the transmission filler bolt and
tighten it to the specified torque.
Gear oil type: SAE 90
Full capacity: 0.23 L
Exchange capacity: 0.18L
CAUTION
Must follow the local regulation and obey the
related prohibition about the disposal of oil.
Transmission Gear Oil change
CAUTION
Use the genuine engine oil or another type with
the same quality and grade to avoid burnout on
the bearing or damage on the gear set.
1
2
1
2
45
