Before reinstalling the drain plug, be sure
to install the O-ring, compression spring
and oil strainer.
E. Clean the oil strainer with solvent.
F. Inspect the O-ring and replace if damaged.
G. Reinstall the O-ring, oil strainer, compression
spring and oil filter cap. Tighten the oil filter
cap to specification.
Tightening torque:
Oil filter cap (engine):
14.7Nm(1.5m-kg,10.6ft-lb)
CAUTION:
H. Fill the engine with oil and install the oil fill
cap.
Recommended oil: see page 138
Oil quantity:
Periodic oil change:
1.4L (1.23 Imp qt, 1.47US qt)
Total amount:
1.6L (1.41 Imp qt, 1.68US qt)
Be sure no foreign material enters the
crankcase.
If oil leakage is found, stop the engine
immediately and check for the cause.
I. Warm up the engine for several minutes at idle
speed. Check for oil leakage while warming
up.
CAUTION:
CAUTION:
103
