Drive select lever
The drive select lever is used for driving the
machine either forward or in reverse. Refer to
page 32 ~ 35 and 47 ~48 for drive select lever
adjustment and operation.
Fuel tank cap
After refueling, be sure to tighten the fuel tank
cap until it clicks.
Insert the breather tube into the handlebar cover
hole.
TO refuel refer to page 36~37.
26
(1) Drive select lever
(R) For reverse drive
(N) Neutral
(F) For forward drive
(1) Fuel tank cap
(2) Breather tube
(3) Handlebar cover hole
(1)
(R)
(N)
(F)
(1)
(2)
(3)
