Wheel removal
1. Elevate the wheel by placing a suitable stand
under the frame.
2. Remove the nuts from the wheel.
3. Remove the wheel assembly.
Wheel installation
When reinstalling a wheel, tighten the wheel
nuts in a crisscross (rather than a circular)
pattern.
Be sure the tapered side of the wheel nuts face
the wheel rim.
Wheel nut torque:
Front: 55
Rear: 55
Nm (5.5 m-kg, 40 ft-lb)
Nm (5.5 m-kg, 40 ft-lb)
126
(1) Safe nut
(1)
POTENTIAL HAZARD
Installing wheels improperly.
WHAT CAN HAPPEN
A wheel may come loose, possibly leading
to an accident.
HOW TO AVOID THE HAZARD
Carefully follow the instructions in this
Owner's Manual when installing.
WARNING
(1)
(2)
OK
(1) Wheel nut (2) Wheel rim
