Battery remove
1. Make sure the ignition switch is OFF.
2. Remove the seat (page 29)
3. Remove the battery holder, by removing the mount
bolts.
4. Disconnect the negative (-) terminal lead from the
battery first, then disconnect the positive (+)
terminal lead.
5. Remove the battery.
Battery installation
1. Install in the reverse order of removal.
2. Check all bolts and other fasteners are secure.
3. After installing the battery, check to see if the
battery cables are routed correctly.
(1) Battery holder
(2) Mount bolt
(3) Negative (-) terminal lead
(4)
(5)
Positive (+) terminal lead
Battery
(1)
(2)
(3)
(4)
(5)
128
