9.DRIVE AND DRIVEN PULLEYS
9-3
TORQUE VALUES
Drive face nut 60 N-m (6 kgf-m, 43 lbf-ft) Apply oil the threads
Clutch outer nut 40 N-m (4 kgf-m, 29 lbf-ft)
Drive plat nut 55 N-m (5.5 kgf-m, 40 lbf-ft)
SPECIAL TOOLS
Universal holder A120E00017 Clutch spring compressor A120E00034
Bearing puller A120E00037 Oil seal and bearing install A120E00014
TROUBLESHOOTING
Engine starts but motorcycle won’t move Lack of power
• Worn drive belt • Worn drive belt
• Broken ramp plate • Weak driven face spring
• Worn or damaged clutch lining • Worn weight roller
• Broken driven face spring • Fouled drive face
Engine stalls or motorcycle creeps
• Broken clutch weight spring
