9.DRIVE AND DRIVEN PULLEYS
9-13
CLUTCH DISASSEMBLY
Remove the circlips to disassemble the
clutch.
CLUTCH / DRIVEN PULLEY ASSEMBLY
Circlip
Clutch Lining
Keep grease off the clutch linings.
＊
