11.CRANKCASE/CRANKSHAFT
11-7
CRANKCASE/CRANKSHAFT
(50cc-2T)
REMOVAL
Remove the crankcase attaching bolts.
Attach the crankcase puller on the right
crankcase and remove the right crankcase
from the left crankcase.
Special tool
Crankcase puller A120E00026
CRANKSHAFT REMOVAL
Attach the crankcase puller on the left
crankcase and remove the crankshaft from
the left crankcase.
Special tool
Crankcase puller A120E00026
When removing the crankshaft, do it
slowly and gently.
＊
Crankcase Pulle
Bolt
When separating the crankcase, the oil
seals must be removed. Replace the oil
seals with new ones.
＊
To Next Page
