11.CRANKSCASE/CRANKSHAFT
11-10
Drive a new crankshaft bearing into the
right crankcase.
Special tool
Oil seal and bearing install A120E00014
Drive a new crankshaft bearing into the left
crankcase.
Special tool
Oil seal and bearing install A120E00014
Install the crankshaft into the left crankcase.
Special tool
Crankshaft install tool A120E00016
Oil Seal And Bearing Install
Crankcase Install Tool
Oil Seal And Bearing Install
• Apply KYMCO ULTRA motor oil o
molybdenum disulfide to the crank-
shaft bearings and connecting rod big
end.
• Apply grease to the lip of the oil seal
and then install it.
＊
