KYMCO Mongoose 50-2T User Manual

13. REAR WHEEL/SWING ARM/
HYDRAULIC BRAKE
13-7
Remove the four bolts and rear axle hub.
INSPECTION
Replace it if the rear axle is scratched
(excessively) or damage.
Replace if splines and threads of the rear
axle is wear or damage.
Measure the rear axle run out.
Service limit: less than 1.5 mm (0.06 in)
Replace if it is out of specification.
Replace it if the driven sprocket is cracks or
damage.
Replace it if splines of the driven sprocket is
wear or damage.
Splines
Do not attempt to straighten a bent axle.
＊
Bolts
Axle Hub
