14. BATTERY/CHARGING SYSTEM/
A.C. GENERATOR
14-3
TORQUE VALUES
A.C.G. flywheel nut 40 N-m (4 kgf-m, 29 lbf-ft)
A.C.G. stator bolt 10 N-m (1 kgf-m, 7 lbf-ft)
Pulser coil bolt 5 N-m (0.5 kgf-m, 3.6 lbf-ft)
Cooling fan 8 N-m (0.8 kgf-m, 6 lbf-ft)
SPECIAL TOOLS
Flywheel puller A120E00001
Universal holder A120E00017
TROUBLESHOOTING
No power Intermittent power
• Dead battery • Loose battery cable connection
• Disconnected battery cable • Loose charging system connection
• Fuse burned out • Loose connection or short circuit in
• Faulty ignition switch
lighting system
Low power Charging system failure
• Weak battery • Loose, broken or shorted wire or connector
• Loose battery connection • Faulty regulator/rectifier
• Charging system failure • Faulty A.C. generator
• Faulty regulator/rectifier
