15. IGNITION SYSTEM
15-6
90cc (ON ROAD) Unit: MΩ
Probe⊕
(
-
)
Probe
Black
Black/
Yellow
Blue/
Yellow
Green
Black ∞∞∞
Black/
Yellow
∞∞∞
Blue/
Yellow
∞∞ ∞
Green 6.1~6.8 6.1~6.8 6.1~6.8
Note: The readings in this table are taken
with a YF-3501 Tester.
50cc –2T (OFF ROAD) Unit: MΩ
Probe⊕
(-)Probe
Black/
Yellow
Black/
Red
Black/
White
Blue/
Yellow
Green
Black/
Yellow
∞∞∞∞
Black/
Red
∞∞15.73 4.63
Black/
White
∞ 8.52 ∞∞
Blue/
Yellow
∞∞∞ ∞
Green
∞∞∞8.07
Note: The readings in this table are taken
with a YF-3501 Tester.
50cc-2T (ON ROAD) Unit: MΩ
Probe⊕
(-)Probe
Black/
Yellow
Black/
Red
Black/
White
Blue/
Yellow
Green
Black/
Yellow
∞∞∞∞
Black/
Red
∞∞∞9.98
Black/
White
∞ 10.2 ∞∞
Blue/
Yellow
∞∞∞ ∞
Green
∞∞∞6.91
Note: The readings in this table are taken
with a YF-3501 Tester.
Blue/Yellow
Green
Black/Yellow
Black/ Red
Black/White
Green
Black
Black
/
Yellow
Blue/Yellow
Blue/Yellow
Green
Black/Yellow
Black/ Red
Black/White
