KYMCO Mongoose 50-2T

5. FUEL SYSTEM
5-12
DISASSEMBLY
Remove auto bystarter cap.
Remove the two screws and then remove
auto bystarter and plate.
Remove the three float chamber screws and
remove the float chamber.
Pull out the float pin, then remove float and
float valve.
Remove the main jet, needle jet holder, and
needle jet.
Remove the slow jet.
Remove the air screw and throttle stop
screw.
Auto Bystarter Cap
Screws
Float Valve
Floa
t
Main Jet/Needle Je
t
Holder/Needle Jet
Auto Bystarte
Screws
Float Chambe
r
Float Pin
Throttle Sto
p
Screw
Slow Je
t
Air Screw
