8-13
K. Install right side cover.
L. Reinstall the drain plug/washer and tighten the drain plug
to the specified torque.
Tightening Torque
Drain plug (engine) 25 N-m (2.5 kgf-m, 18 lbf-ft)
M. Add the specified amount of recommended engine oil,
and then install the engine oil filler cap and tighten it.
Recommended oil: see CH 9.3.
Oil quantity: see CH 9.3.
Be sure no foreign material enters the crankcase.
N. Start the engine and warm it up for several minutes.
While warming up, check for oil leakage. If oil leakage is
found, turn the engine off immediately and check for the
cause.
O. Turn the engine off, and then check the oil level through
the inspection window and correct it if necessary.
