8-37
8.21. FUSE REPLACEMENT
The fuse box (1) is located in a compartment under the front
cover.
To replace a fuse:
1. Make sure the ignition switch is OFF.
To prevent accidental short-circuiting, turn off the main switch
when checking or replacing a fuse.
(1) Fuse box
2. Remove the front cover
3. Open the fuse box cap.
4. Pull the old fuse out of the fuse holder.
5. Push the new fuse in to the fuse holder.
6. Close the fuse box cap and install front cover.
Fuse specifications
