8-15
3. Fill the gear case with the recommended oil.
Recommended oil SAE 90
Oil quantity
Periodic oil change 0.23 L (0.20 lmp qt, 0.243 US qt)
4. Remove the oil level check bolt/washer (3).
Make sure the oil level reaches the oil level check hole.
5. Install the oil filler cap and oil level check bolt.
Tightening Torque
Oil filler cap 14.7 N-m (1.5 kgf-m, 11 lbf-ft)
Oil level check bolt 20 N-m (2 kgf-m, 15 lbf-ft)
6. Install the skid plate.
Be sure no foreign material enters the gear case.
