8-17
5. Fill the gear case with the recommended oil.
Recommended oil SAE 90
Oil quantity
Periodic oil change 0.25 L (0.22 lmp qt, 0.265 US qt)
6. Remove the oil level check bolt/washer
Make sure the oil level reaches the oil level check hole.
7. Install the oil filler cap and oil level check bolt.
Tightening Torque
Oil filler cap 15 N-m (1.5 kgf-m, 11 lbf-ft)
Oil level check bolt 10 N-m (1 kgf-m, 7.2 lbf-ft)
Be sure no foreign material enters the gear case.
