8-28
(1) MAX level mark (Foot brake pedal)
(2) MIN level mark (Foot brake pedal)
NOTE
As the brake pads wear, brake fluid level drops,
automatically compensating for wear. There are no
adjustments to perform, but fluid level and pad wear must
be inspected periodically. The system must be inspected
frequently to ensure there are no fluid leaks.
If the brake lever travel become excessive and the brake
pads are not worn beyond the recommended limit (CH
8.14), there is probably air in the brake system and it
must be bled. See your authorized KYMCO dealer for
To prevent damage to the brake system, use only fluid
from a sealed container. Never allow contaminants (dirt,
water, etc.) to enter the brake fluid reservoir.
Brake fluid can damage paint and plastic, so handle the
fluid with care. When adding brake fluid, be sure the
reservoir is horizontal before removing the cover to
prevent accidental spilling.
Use only DOT 4 brake fluid from a sealed container.
