13. FUEL INJECTION SYSTEM
13-0
X-Town300 ABS
13
__________________________________________________________________________________
__________________________________________________________________________________
FUEL INJECTION SYSTEM
__________________________________________________________________________________
SERVICE INFORMATION ------------------------------------------------ 13- 1
SPECIFICATIONS ---------------------------------------------------------- 13- 2
INJECTION SYSTEM DIAGRAM --------------------------------------- 13- 3
PARTS LOCATION -------------------------------------------------------- 13- 4
TROUBLESHOOTING ----------------------------------------------------- 13- 6
SELF-DIAGNOSTIC PROCEDURES WITHOUT
DIAGNOSTIC TOOL ------------------------------------------------------- 13- 7
EFI SELF-DIAGNOSIS CHECK ENGINE LAMP (CELP) FAILURE
CODES-------------------------------------------------------------------------13-8
SELF-DIAGNOSIS RESET PROCEDURE ----------------------------- 13- 9
CELP FAILURE CODES LIST ------------------------------------------ 13-10
TPS/ISC RESET ----------------------------------------------------------- 13-13
FUEL PUMP ---------------------------------------------------------------- 13-14
FUEL CUT-OFF RELAY ------------------------------------------------- 13-16
TILT SWITCH -------------------------------------------------------------- 13-17
ELECTRONIC CONTROL UNIT (ECU) ------------------------------- 13-18
FUEL INJECTOR ---------------------------------------------------------- 13-20
WTS SENSOR -------------------------------------------------------------- 13-22
O
2
SENSOR ----------------------------------------------------------------- 13-23
THROTTLE BODY/MAP/ISC/TPS ------------------------------------- 13-24
DIAGNOSTIC TOOL CONNECTOR ----------------------------------- 13-27
DIAGNOSTIC TOOL OPERATION INSTRUCTIONS -------------- 13-28
VEHICLE CAN NOT BE STARTED ----------------------------------- 13-40
MANUAL TROUBLE SHOOTING PROCEDURE ------------------- 13-41
13
6
