6. CYLINDER HEAD/VALVES
CYLINDER HEAD COVER REMOVAL
Remove the met-in box.
Remove the body cover and center cover.
Disconnect the breather hose to air cleaner.
Remove the cylinder head cover four bolts.
Remove the cylinder head cover.
CAMSHAFT REMOVAL
Remove the injector and inlet pipe.
Remove two screws attaching the
thermostat.
Turn the cam chain tensioner screw
clockwise to tighten it.
Torque: 1.0 kgf-m (9.8 N-m)
