13. FUEL INJECTION SYSTEM
FUEL INJECTOR
INSPECTION
Disconnect the fuel injector connector.
Measure the resistance between 2 pins of the
fuel injector connector.
Standard: 11.7±0.6 Ω (at 20°C/68°F)
REMOVAL
Disconnect the connector from the fuel
injector.
Remove the bolt of the fuel injector.
Take out of the fuel pipe and fuel injector
from the Inlet pipe.
Remove the fuel injector from the fuel pipe.
Ensure the fuel pipe without any
pressure, then remove the fuel injector.
STEP 1: Disconnect the fuel pump relay
or fuel pump connector.
STEP 2: Turn the key to the ON
position. Starting the engine till the
engine stop working.
To Next Page
